Warranty Information
SCNN-01-V01-R1 End User Manual Smartcard Meter
March 2023 Page 12 of 12
Refund credit from the meter
Any credit remaining on the meter can be transferred back to the Smartcard, allowing the
card to be used another service/meter or to be returned it to the issuing office for a
refund.
NOTE: Credit on the meter can only be transferred to the same Smartcard that issued
the credit.
Smartcard Meter Specifications
Compliance IEC 65052-11
Working Voltage 230 V
Rated Current 63 Amp
Impulse Constant 1000 imp/kWh
Frequency 50 Hz
Accuracy Class 1
Display Mode LCD 6+2
Working Temperature -20 to +55 °C
Storage Temperature -25 to +70 °C
Power Consumption <1.2W
Average Humidity <75%
Start Current 0.4 % IB
Protection Class IP51
Dimensions (mm) 171.5 H x 106 W x 54.5 D
Warranty Information
The Smartcard meter and USB card reader/writer are covered by a 1 year warranty.
To Refund Credit from the Meter
1. Press and hold the red
button then insert card.
2. When the meter displays
“b_good” remove the card
and release the red button.
The credit has now been
transferred back to the
card.
