Configuration
SCNN-01-V01-R1 End User Manual Smartcard Meter
March 2023 Page 6 of 12
Log In
1. Enter the login password that was
created during the installation
process, then click on the LOGIN
button.
2. After logging in, click the CONNECT
TO CARD READER button.
The card reader will beep when it
has successfully connected.
Create a User Card
1. Insert a new card into the card
reader with the chip facing up and
click the READ CARD button.
2. If the card is valid and unused the
software will display New Card.
3. Click on the CREATE USER CARD
button and enter the required
details.
NOTE: The card number is created automatically based on a sequential numbering
system. The Customer ID field is optional and would contain a reference or account
code for the customer you could, for example, also store the customers vehicle
registration number.
4. Enter the customer’s name into the Card Holder field and their contact phone
number into the Phone field. The Location field should contain a reference to the
required pitch and/or smart meter.
5. When all required details have been entered click the WRITE TO CARD button to
store the details on the Smartcard.
6. The card is now ready to add credit as required.
