The roller capsule (4) must have at least 2/3 of its length inserted
into the winding shaft (5).
Correct for slight dimensional accuracies by sliding the roller
capsule (4) in or out.
3.
1.
The adjustment screws (11) must be accessible.
The tubular motors can be installed in the click bearing (13) in 4po-
sitions. By spreading the bracket (14), you can remove the motors
from the click bearing (13) again at any time.
NOTE
If you are using a different drive bearing than the RADEMACHER
click bearing, you may now need to secure the drive with another
splint.
Press the drive head (12) lightly into the drive bearing (13) until
it engages.
Insert the other end of the winding shaft (5) with the ball bearing (2)
into the counter bearing (1).
2.
Secure the roller capsule (4) with a screw afterward.
IMPORTANT
Counter bearing (1)
Place the drive head (12) on the drive bearing and secure it appro-
priately, such as with a splint.
Drive bearing (13) - as a click bearing
Drive bearing (13) - all other bearing variants
49
Installing the motor in the bearings (Figure )
6
GB
