Assemble the Shock Absorbers
1. Take out the screw (19), washer (18), wrench (20) and
nut (26) from the blister pack.
2. Align the shock absorber (B) with the metal holes.
3. Insert the screw (19) through the holes. Then slide the washer
and screw nut onto the screw.
4. Fasten with a screwdriver and wrench.
5. Repeat steps 1-4 for the other three shock absorbers.
(A)
(B)
20
19
26
18
