Rollplay W421 - Parts Identification

7
Parts
• 2 AAA batteries
8
11
2
4
5
5
3
13
12
25
12
14
13
14
10
5
5
1
Helpful Tip:
1. Parts 16-26 are located
in the blister pack
2.
3.
Spare parts: 2 bolts.
Rear wheels are marked
with an "R" and front wheels
are marked with an "F"
• Phillips screwdriver
Not Included:
15
16
17
19
20
21
22
23
24
26
18
28
15. Hex Wrench
16. Steering Wheel Screw M5x50
17. Steering Wheel Nut M5
18. Φ8 Washers (4)
19. Screws M8X38（4）
20. Wrench
21. Brush Guard Screws M6X48 (2)
22. Brush Guard Nuts M6 (2)
23. Bolt ST4.2x15
24. Screw M4x18
25. Screw Nut M4
26. Screw Nuts M8 (4)
27. Φ6 Washers (2)
28. Blister Pack
1. Manual
2. 24V Battery
3. Steering Wheel
4. Exhaust Stack
5. Wheel Covers (4)
6. Front Wheels (2)
7. Rear Wheels (2)
8. Car Body
9. Brush Guard
10. Seat
11. Battery Charger
12. Φ12 Front Washers (2)
13. Φ10 Front/Rear Washers (4)
14. M10 Front/Rear Wheel Nuts (4)
27
6
6
7
7
9
