1. Locate the brush guard, 2 M6x48 screws (21), 2 Φ6 washers (27)
and 2 M6 nuts (22). The screws and nuts are located in the blister
pack.
2. Align the holes on the brush guard with the holes on the metal frame
under the front bumper.
3. Insert the Φ6 washers (27) and screws into the holes through the
brush guard and frame, then secure them with the nuts.
21
22
27
15
Assemble the Brush Guard
