11
Assemble the Front Wheels
1. Take out the Φ12 front washers (12), Φ10 front/rear washers (13)
and nut (14) from the blister pack.
2. Slide a Φ12 front washer (12) and front wheel onto the axle.
3. Slide a Φ10 front/rear washer (13) and wheel nut (14) onto the axle,
then use the hex wrench (15) to tighten.
4. Snap on the wheel cover by aligning the tabs on the cover with
the slots on the wheel and press until it clicks into place.
5. Repeat these steps for the other front wheel.
12
14
13
Helpful Tip:
1. The side of the
wheel with
rectangular tabs
should face outward
and the side
marked with an "F"
faces inwards.
