14
Fasten the TOP (A) to a SKIRT (J2). Tighten two HIDDEN CAMS.
Fasten the TOP (A) to the SIDE SKIRTS (K). Tighten four HIDDEN CAMS.
NOTE: The SKIRT on the TOP should be located toward the back of the unit.
Fasten a SKIRT (J2) to the BOTTOM SHELF (D2). Tighten two HIDDEN CAMS.
417087
step 9.
Serious or fatal crushing injuries can occur
from furniture tip-over. To help prevent
tip-over:
• Install tip-over restraint provided.
• Place heaviest items on the lowest surfaces as
far back from the front edge as possible.
• Unless specifi cally designed to accommodate,
do not set TVs or other heavy objects on top of
this item.
• Never allow children to hang on drawers, doors
or shelves.
Use of tip-over restraints may only reduce, but
not eliminate, the risk of tip-over.
This is a permanent label. Do not attempt to remove!
WARNING
Caution
Risk of damage or injury. Hidden Cams must
be completely tightened. Hidden Cams that
are not completely tightened may loosen, and
parts may separate. To completely tighten:
Tighten
Maximum
210 degrees
Arrow
Minimum
190 degrees
Start
Arrow
Surface with holes
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
A
D2
J2
J2
K
K
To Next Page
