Technical data
Page 12 RES-415 Version 1
Degree of protection Front: IP42 (IP65 with transparent front cover, Art. No. 887000)
Back: IP20
Installation Installed in front panel cutout with (W x H) 138
(+-0.2)
x68
(+-0.2)
mm
Fastened with clips
Weight Approx. 1.0kg (incl. connector plug-in parts)
Housing material Black plastic, type Noryl SE1 GFN2
Connecting cable
Type / cross-sections
Rigid or flexible; 0.2…2.5mm² (AWG 24…12)
Plug-in connectors
If ferrules are used, they must be crimped in accordance
with DIN 46228 and IEC/EN 60947-1.
This is essential for proper electrical contact in the terminals.
