6 Technical data
Type of construction Housing for front panel mounting
Dimensions (W x H): 144 x 72mm; depth: 161mm (incl. terminals)
Line voltage All controller manufactured as of
February 2006
(as of software revision 100):
115VAC version: 110VAC -15%…120VAC +10% (equivalent to 94…132VAC)
230VAC version: 220VAC -15%…240VAC +10% (equivalent to 187…264VAC)
400VAC version: 380VAC -15%…415VAC +10% (equivalent to 323…456VAC)
All controllers manufactured as of January 2004 up to
January 2006
(up to software revision 027):
115VAC version: 115VAC -15%…120VAC +10% (equivalent to 98…132VAC)
230VAC version: 230VAC -15%…240VAC +10% (equivalent to 196…264VAC)
400VAC version: 400VAC -15%…415VAC +10% (equivalent to 340…456VAC)
All controllers manufactured up to December 2003:
115VAC, 230VAC or 400VAC, tolerance: +10% / -15%
depending on device version ( section 13 "How to order" on page 41)
Line frequency 47…63Hz, automatic adjustment to frequencies in this range
Heatsealing band
type and temperature
range
As of software revision 100:
The temperature range and temperature coefficient settings can be specified in
the ROPEX visualization software ( section 10.10 "Diagnostic interface/visuali-
zation software (as of software revision 100)" on page 33):
Temperature range: 200°C, 300°C, 400°C or 500°C
Temperature coefficient: 400…4000ppm (variable setting range)
Factory setting: Temperature range: 0…300°C
Temperature coefficient: 1100ppm (e.g. Alloy A20)
Set point selection Via the "UP / "DOWN" keys on the front of the controller
Digital logic levels
Terminals 3, 4
LOW (0V): 0…2VDC
HIGH (24VDC): 12…30VDC (max. current input 6mA)
Electrically isolated, reverse polarity-protected
START with contact
Terminals 2+7
Switching threshold: 3.5VDC, U
max
= 5VDC, I
max
=5mA
Alarm relay
Terminals 5+6
Contact, potential-free, U
max
= 30V (DC/AC), I
max
=0.2A
Maximum load
(primary current of
impulse transformer)
I
max
= 5A (duty cycle = 100%)
I
max
= 25A (duty cycle = 20%)
Power dissipation max. 25W
Display LC display (green), 4 lines, 20 characters, alternatively:
VF display (blue), 4 lines, 20 characters
Ambient temperature +5…+45°C
