22
MODEL 54e pH/ORP SECTION 5.0
SOFTWARE CONFIGURATION
ITEM RANGES FACTORY SETTINGS USER SETTINGS
2b. Output 1 Setup (PID)
(a) Setpoint -2 to 16 pH or -15 to 130°C 7 pH _______
(b) Proportional 0-299.9% 100.0% _______
(c) Integral 0-2999 sec 0 sec _______
(d) Derivative 0-299.9% 0.0% _______
(e) LRV (4 mA) -2 to 16 pH or -15 to 130°C 2 pH _______
(f) URV (20 mA) -2 to 16 pH or -15 to 130°C 0 pH _______
3. Output 2 Control
(a) Output 2 Measurement Process/Temp/Glass Imp/Ref Imp Temperature _______
(b) Output 2 Control Mode Normal/PID Normal _______
4a. Output 2 Setup (Normal)
(a) Current Range 4-20 mA/0-20 mA 4-20 mA _______
(b) Dampening 0-255 Sec 0 Sec _______
(c) Hold Mode Last value/Fixed value Last value _______
(d) Fixed Hold Value (if (c) Fixed) 0-22 mA 21 mA _______
(e) Fault value 0-22 mA 22 mA _______
4b. Output 2 Setup (PID)
(a) Setpoint -2 to 16 pH or -15 to 130°C 7 pH _______
(b) Proportional 0-299.9% 100.0% _______
(c) Integral 0-2999 sec 0 sec _______
(d) Derivative 0-299.9% 0.0% _______
(e) LRV (4 mA) -2 to 16 pH or -15 to 130°C 2 pH _______
(f) URV (20 mA) -2 to 16 pH or -15 to 130°C 0 pH _______
5. Hold (Outputs and Relays) Disable/Enable/ 20 min timeout Disable feature _______
C. Alarms (Section 5.7)
1. Alarm 1 Control
(a) Activation Method Process/Temp Process _______
(b) Alarm 1 Control Mode Normal/TPC Normal _______
2a. Alarm 1 Setup (Normal)
(a) Configuration Low alarm/High alarm/Off Low _______
(b) Hysteresis (deadband) 0 - 5.00 pH 0.01 pH _______
(c) Delay Time 0-99 sec 0 sec _______
(d) Relay Fault Open/Closed/None None _______
2b. Alarm 1 Setup (TPC)
(a) Setpoint -2 to 16 pH or -15 to 130°C 7 pH _______
(b) Proportional 0-299.9% 100.0% _______
(c) Integral 0-2999 sec 0 sec _______
(d) Derivative 0-299.9% 0.0% _______
(e) Time Period 10-2999 sec 30 sec _______
(f) LRV (100% On) -2 to 16 pH or -15 to 130°C 2 pH _______
(g) URV (100% Off) -2 to 16 pH or -15 to 130°C 0 pH _______
(h) Relay Fault None/Open/Closed None _______
3. Alarm 2 Control
(a) Activation Method Process/Temp Process _______
(b) Alarm 2 Control Mode Normal/TPC Normal _______
4a. Alarm 2 Setup (Normal)
(a) Configuration Low alarm/High alarm/Off High _______
(b) Hysteresis (deadband) 0 - 5.00 pH 0.01 pH _______
(c) Delay Time 0-99 sec 0 sec _______
(d) Relay Fault Open/Closed/None None _______
4b. Alarm 2 Setup (TPC)
(a) Setpoint -2 to 16 pH or -15 to 130°C 7 pH _______
(b) Proportional 0-299.9% 100.0% _______
(c) Integral 0-2999 sec 0 sec _______
(d) Derivative 0-299.9% 0.0% _______
(e) Time Period 10-2999 sec 30 sec _______
(f) LRV (100% On) -2 to 16 pH or -15 to 130°C 2 pH _______
(g) URV (100% Off) -2 to 16 pH or -15 to 130°C 0 pH _______
(h) Relay Fault None/Open/Closed None _______
TABLE 5-1. pH Settings List (continued)
Continued on the following page
