MODEL 54e pH/ORP APPENDIX A
ORP CONFIGURATION
ITEM CHOICES ORP SETTINGS USER SETTINGS
PROGRAM LEVEL (Sections A.2 - A.3)
A. Alarm Setpoints (Section A.2)
1. Alarm 1 (low action) -1400 to +1400 mV -1400 mV _______
2. Alarm 2 (high action) -1400 to +1400 mV +1400 mV _______
3. Alarm 3 (high action) -1400 to +1400 mV +1400 mV _______
B. Output Setpoints (Section A.3)
1. Output 1: 4 mA -1400 to +1400 mV -1400 mV _______
2. Output 1: 20 mA -1400 to +1400 mV +1400 mV _______
3. Output 2: 4 mA -15 to 130 °C 0.0 °C _______
4. Output 2: 20 mA -15 to 130 °C 100.0 °C _______
CONFIGURE LEVEL (Sections 5.5 - 5.9)
A. Display (Section 5.5)
1. Measurement type pH/ORP ORP _______
2. Convention ORP/Redox ORP _______
3. Temperature Units °C/°F °C _______
4. Output 1 Units mA/% of full scale mA _______
5. Output 2 Units mA/% of full scale mA _______
6. Language English/Français/Español/Deutsch/Italiano English _______
7. Main display lower left See Section 5.5 Alarm 1 Setpoint _______
8. Main display lower right See Section 5.5 Alarm 2 Setpoint _______
9. Display contrast 0-9 (9 darkest) 5 _______
10. Tests Timeout On/Off On _______
11. Timeout Value 1-60 min 10 min _______
B. Outputs (Section 5.6)
1. Output 1 Control
(a) Output 1 Measurement Process/Temp/Ref Imp Process (ORP) _______
(b) Output 1 Control Mode Normal/PID Normal _______
2. Output 1 Setup
(a) Current Range 4-20 mA/0-20 mA 4-20 mA _______
(b) Dampening 0-299 Sec 0 Sec _______
(c) Hold Mode Last value/Fixed value Last value _______
(d) Fixed Hold Value (if (c) Fixed) 0-22 mA 21 mA _______
(e) Fault Value 0-22 mA 22 mA _______
3. Output 2 Control
(a) Output 2 Measurement Process/Temp /Ref Imp Temperature _______
(b) Output 2 Control Mode Normal/PID Normal _______
4. Output 2 Setup
(a) Current Range 4-20 mA/0-20 mA 4-20 mA _______
(b) Dampening 0-255 Sec 0 Sec _______
(c) Hold Mode Last value/Fixed value Last value _______
(d) Fixed Hold Value (if (c) Fixed) 0-22 mA 21 mA _______
(e) Fault Value 0-22 mA 22 mA _______
5. Hold (Outputs and Relays) Disable/Enable/ 20 min timeout Disable feature _______
C. Alarms (Section 5.7)
1. Alarm 1 Control
(a) Activation Method Process/Temp Process(ORP) _______
(b) Alarm 1 Control Mode Normal/TPC Normal _______
TABLE A-1. ORP Settings List
Continued on the following page.
