MODEL 54e pH/ORP SECTION 5.0
SOFTWARE CONFIGURATION
Accessing Calibrate, Program and Configure
Menus. Operating configuration changes are made
at the levels shown in Figure 5-1. Pressing any key
from the main display will access the main menu (top
left). Refer to Appendix A for ORP measurements.
Level 1 Calibrate. To access calibration selections
from the main menu, with the cursor on "Calibrate"
press Enter (F4). All buffer calibration, pH standardi-
zation and temperature adjustments are made at this
level (refer to Section 4.0 for these procedures).
Level 2 Program. To access the program level from
the main menu, place the cursor over "Program" with
the down arrow key. Then press Enter (F4). From the
program level menu, changes can be made to the
alarm setpoints and the output setpoints.
Level 3 Configure. To access the configure level
from the main menu place cursor over "Program" and
Enter (F4), then place cursor over "Configure" and
Enter (F4). This level contains advanced selections,
such as alarms, diagnostics, autocal and others.
24
FIGURE 5-1. Outline of Menu Levels
PRESS TWO ARROWS
>>
and then ENTER
PRESS ENTER
PRESS ARROWS
>>
PRESS
ARROWS
>>
PRESS
ARROWS
>>
PRESS
ARROWS
>>
PRESS
ENTER
Calibrate
Diagnostic variables
Program
Exit Enter
Alarm setpoints
Output setpoints
Simulated tests
Exit Enter
Simulated tests
Configure
Exit Enter
Display
Outputs
Alarms
Exit More Enter
CALIBRATE MENU SECTION
Buffer Calibration 4.2, 4.3
Standardize pH 4.4
Adjust Temperature 4.1
Temp Compensation 4.5
pH slope 4.6
CONFIGURE MENU SECTION
Display 5.5
Outputs 5.6
Alarms 5.7
Diagnostics 5.8
Calibration 5.9
Security 7.1
Temperature Coeff 7.3
PROGRAM MENU SECTION
Alarm setpoints 5.1
Output setpoints 5.2
Output setpoints (PID) 5.3
Simulated tests 5.4
Alarms
Diagnostics
Calibration
Exit More Enter
Security
Temperature coeff
Exit More Enter
Buffer calibration
Standardize
Adjust temperature
Exit Enter
Adjust temperature
Temp Compensation
pH slope
Exit Enter
