5–2 • Operating the NK-Hub NK-Hub User Guide (v01)
Connected — displays the connection status:
• — not connected
• — connected
Comms — displays the T-Bus comms traffic on the NK-IPS:
• — T-Bus idle
• — T-Bus active
Connect Button
Click this button to connect to the NK-IPS devices listed in the IPS table.
Add Button
Click this button to add another row to the IPS table.
Remove Button
Click this button to remove the selected row in the IPS table.
Connect On Startup
Select this check box to automatically connect the NK-Hub to all devices listed in the IPS table on startup.
Adding NK-IPS Devices
Use the following procedure to add NK-IPS devices to the NK-Hub.
To add NK-IPS devices:
1. Using the DashBoard NK Plugin, find out the IP address and port for each NK-IPS device to be connected:
a. In DashBoard, place the cursor over the NK-IPS in the Basic Tree View.
A popup displays the IP address.
b. Double-click the NK-IPS to open the editor.
A tab for the NK-IPS opens in the main window. The Client TCP Port field displays the port number.
