Rosslare AC-015 User Manual

AC-015 Page 9 March 2008
Technical Specifications
Electrical Characteristics
Main Unit
Operating
Voltage:
16V AC (1.5A, 25VA)
From a transformer
Maximum Input
Current:
(Not including
attached devices)
Standby: 65mA
Maximum: 120mA
Battery Charger:
12V DC Lead Acid Battery
Up to 7AH recommended
Outputs
Lock Strike Relay
Output:
5A Relay
Lock Strike Power
Supply:
12V DC constant voltage
1.2 A current limit
N.O. or N.C. option
Tamper Relay
Output
1A Relay N.C. Dry Contact
Reader Power
Supply:
Voltage: 12V DC
Max Current: 300mA
Inputs
Release to Exit
(REX):
N.O. Dry Contact
Two Reader Inputs:
26-Bit Wiegand Compatible

Rosslare AC-015 Specifications

General

Brand	Rosslare
Model	AC-015
Category	IP Access Controllers
Language	English
