Rosslare AC-015 User Manual

AC-015 Page 13 March 2008
screws provided with your US Gang Box when
mounting to a US Gang Box.
6) Wire the controller according to the diagrams on
the next few pages.
7) Return and secure the front case using the security
screw and security tool provided in the Installation
Kit.
0
8
5
21
46
3
97
#
MODE DOOR
Case Screw
3 x 4 Matrix Keypad
Bell Button
Door LED
Mode LED
You now have mechanically installed the controller.

Rosslare AC-015 Specifications

General

Brand	Rosslare
Model	AC-015
Category	IP Access Controllers
Language	English
