Reader Functionality
AYC-Fx4 and AYC-Gx4 family manual Page 15
Mode/Transmit
Door/Program
Red
Programming Menu System the AYC-Fx4/AYC-Gx4 must first be
placed into Programming Mode. During the AYC-Fx4/AYC-Gx4
manufacturing process certain codes and settings are pre-
programmed. These settings are the called the "Default Factory
Settings". The table below shows the names of all the AYC-
Fx4/AYC-Gx4 Menus.
Programming Menu
Default Factory Settings are marked by a "*" sign.
Menu Description
Default
1
Selecting Keypad Transmission Format
Single Key, 6-Bit Wiegand (Rosslare Format)
Single Key, 6-Bit Wiegand with Nibble + Parity Bits
Single Key, 8-Bit Wiegand, Nibbles Complemented
4 Keys Binary + Facility Code, 26-Bit Wiegand
1 to 5 Keys + Facility Code, 26-Bit Wiegand
6 Keys BCD and Parity Bits, 26-Bit Wiegand
Single Key, 3x4 Matrix Keypad
1 to 8 Keys BCD, Clock & Data
*
2
Selecting Card Transmission Format
26-Bit Wiegand
Clock & Data
Wiegand Card + PIN
*
3
Changing the Programming Code
1234
4 Changing the Facility Code 0
0
Return to Factory Default Settings
Entering Programming Mode
1) Press the # key 4 times.
• Transmit LED will turn off.
• Program LED will turn red.
2) Enter your 4 digit Programming Code.
If the Programming Code is
valid, the door LED will turn
?
?
?
?
Mode/Transmit
Door/Program
Green
