Rosslare AYC-Q64B - Wiring Instructions; Controller Application Wiring Diagram #1; Controller Application Wiring Diagram #2

Technical Specifications
12 AYC-Qx4 Family Installation and Programming Manual
Specifications AYC-Q54B AYC-Q64B
Physical Characteristics
Size
(Height x Width x Depth)
120 x 76 x 21 mm (4.7 x 3.0 x 0.8 in.)
Weight
480 g (1.1 lb)
* Measured using a Rosslare proximity card or equivalent. Range also depends
on electrical environment and proximity to metal.
