Technical Specifications
AYC-Qx4 Family Installation and Programming Manual 11
2. Technical Specifications
Specifications AYC-Q54B AYC-Q64B
Electrical Characteristics
Power Supply Type
Linear (recommended)
Operating Voltage Range
5 to 16 VDC (when used as a controller,
provided by the secured intelligent
power supply)
Input Current Standby (12 VDC)
65 mA 90 mA
Maximum Input Current (16 VDC)
110 mA 130 mA
LED Control Input
Dry contact N.O.
Tamper Output
Open collector, active low, 30 mA max
sink current
Cable Distance to Host Controller
Up to 150 m (500 ft) using an 18 AWG
cable
Max. Proximity Card Read Range*
N/A 45 mm (1.8 in.)
Proximity Card Modulation
N/A ASK at 125 KHz
Proximity Card Compatibility
N/A EM cards
Card Transmit Format (Reader)
N/A Wiegand 26-Bit, or
Clock & Data
Keypad Transmit Format (Reader)
Programmable PIN code formats
LED Indicators
Two tri-colored LEDs
Communication
Data1/C1, Data0/C2 – open collector, 5
V termination
Environmental Characteristics
Operating Temperature Range
-35°C to 66°C (-31°F to 151°F)
Operating Humidity Range
0 to 95% (non-condensing)
Outdoor Usage
Weather-resistant, meets IP65, epoxy
potted, suitable for outdoor use
