20) FITTING THE CHUCK
 The machine comes supplied with an RDD4128 (Arbor Shank) & RDD4126 (16mm
Chuck).
 Insert RDD4128 into RDD4022 (Arbor Spindle), ensure a good and tight fit is
achieved.
 Insert RDD4126 into RDD4128, ensure a good and tight fit is achieved.
 Replacing the chuck is the reverse sequence, by utilising RDD4129 (Drift).
21) MAINTENANCE
In order to ‘get the best life’ out of your Rotabroach machine always keep it in good
working order.
A number of items must always be checked on Rotabroach machines.
Always before starting any job make sure the machine is in good working order and that
there are no damaged or loose parts. Any loose parts must be tightened.
Before proceeding with any maintenance work be certain that the power supply is
disconnected.
Description
Every operation
1 week
1 Month
Visual check of
machine for damage
X
Operation of machine
X
Check brush wear
X
Check magnetic base
X
Check alignment of
the machine
X
Check grease
X
Check armature
X
Visually check the machine for damage.
The machine must be checked before operation for any signs of damage that will affect the
operation of the machine. Particular notice must be taken to the mains cable, if the machine
appears to be damaged it should not be used, failure to do so may cause injury or death.
Check operation of the machine.
The machines operation must be checked to ensure that all components are working
correctly.
Machine Brushes
Should be checked to make sure there is no abnormal wear present (this should be checked
at least once a week if used frequently). If the brush has worn more than 2/3 of the original
length, the brushes should be changed. Failure to do so may cause damage to the machine.
