Rotabroach SMARTPANTHER1 - Machine Specification

Issue 3 Original version March 2012
- 5 -
3) Specification
Maximum hole cutting capacity in .2/.3C steel = 40mm dia. x 52mm deep
Arbor bore = 19.05mm (3/4”) dia.
Motor Unit
(Nominal values)
Smartpanther1
110v 50-60Hz
1100W
Smartpanther3
230v 50-60Hz
1100W
Electro Magnet
Smartpanther1
110v 50-60Hz
45W
Smartpanther3
230v 50-60Hz
45W
Total Normal Full Load (magnet + motor)
1145
Overall
Dimensions
Height (maximum extended)
510 mm
Width (including Hand wheel)
180 mm
Length Overall (including Guard)
265 mm
Magnet Footprint
165mm x 80mm
Nett Weight
14.6 kg
Stroke
85mm
No Load speed
All voltages
270-610 rpm
Tractive Force of Magnet at 20º C (25mm min. plate thickness)
The use on any material less than 25mm thick will progressively reduce
the magnetic performance. If possible substitute material should be
positioned under the magnet and work piece to equate to a suitable
material thickness. If this is not possible an alternative secure method of
restraining the machine MUST be used. Failure to do so may result in
personal injury.
800kg
Maximum hand/arm vibration magnitude (measured at handle during
operation in accordance with ISO5349 using a 22mm dia. cutter through
13mm mild steel plate.
2.892 m/s²
Estimate of vibration exposure. Operation 30 holes @ 1 minute/hole.
0.13 m/s² A(8)
Average noise level during cutting at operators ear position.
L
PA
Max. 88.4 dB(A)
L
WA
Max. 101.4dB(A)
Ear defenders must be worn when operating this machine.
Suitable only for a single phase 50-60 Hz A.C. power supply.
DO NOT USE ON D.C. SUPPLY
Do not use the magnetic drill on the same structure when arc welding is in progress.
D.C. current will earth back through the magnet and cause irreparable damage.
WARNING: THIS APPLIANCE MUST BE EARTHED!
NB: ANY MODIFICATIONS TO THIS MACHINE WILL INVALIDATE THE GUARANTEE.
List of Contents with Magnetic Dill Unit
Check List
RD4329
Safety Strap
YES/NO
RD4088
4mm A/F Tee Handled Hexagon Key
YES/NO
RD4152
3mm Hexagon key
YES/NO
