Rotabroach SMARTPANTHER1 - Chuck Conversion; Maintenance Checks

Issue 3 Original Version March 2012
- 16 -
12) CHUCK CONVERSION.
 To remove the arbour lay the machine on its side.
 Unscrew the two grub screws at the top of the arbor
 Some early machines will only have spanner flats on the arbor.
 When the arbor has become detached from the spindle this can then be removed
 Remove the arbour support bracket and guard with the arbour retained.
 Mount the chuck using the chuck adaptor RD33153.
 Replacing the chuck is the reverse sequence.
13) Tips for keeping your machine in correct working
order.
In order to ‘get the best life’ out of your Rotabroach machine always keep in good
working order. A well maintained machine is a happy machine.
A number of items must always be checked on Rotabroach machines.
Always before starting any job make sure the machine is in good working order and that there are
no damaged or loose parts. Any loose parts must be tightened.
Before proceeding with any maintenance work be certain that the power supply is
disconnected.
Description
Every operation
1 week
1 Month
Visual check of
machine for damage
X
Operation of machine
X
Check brush wear
X
Check magnetic base
X
Check alignment of
the machine
X
Check grease
X
Check Armature
X
Visually check the machine for damage.
Machine must be checked before operation for any signs of damage that will affect the operation
of the machine. Particular notice must be taken of the mains cable, if the machine appears to be
damaged it should not be used failure to do so may cause injury or death.
Check operation of the machine.
The machines operation must be checked to ensure that all components are working correctly.
