Rotary 600 Series - Latch Cable Adjustment

12
A
B
Equalizer Cable Adjustment:
Press
andraiselifttocheckequalizercabletension.Below
carriage,graspadjacentcablesbetweenthumbandforenger,
with about 15 lbs., Fig. 5, effort you should just pull the cables
together. Adjust at upper tie-offs, Fig. 6.
LATCH CABLE ADJUSTMENT
Fig.6Detail
A Uppercabletieoffplateand1/2"
nylon insert lock nut
B
Lowercabletieoffplateand1/2"
nylon insert lock nut
Fig. 5
Fig. 6
