Rotax 914 series Service Instruction

d06525.fm
20 December 2017 12-10-00
page 10 of 13
Copyright - BRP-Rotax GmbH & CO KG. All rights reserved.
SI-912 i-001R5 / SI-915 i-001
SI-912-016R10 / SI-914-019R10
SERVICE INSTRUCTION
5.3) Fuel according to local standards
The following fuels can be used.
NOTE: There is a risk of vapor lock formation if winter fuel is used for summer
operation.
Engine Type 912 A/F/UL - 912 S/ULS - 914 F/UL
m
WARNUNG
NOTICE
Use only the correct fuel for the specific climate zones.
Usage/Description
912 A/F/UL
Min. RON 90
912 S/ULS - 914 F/UL
Min. RON 95
MOGAS
European
standard
EN 228 Normal
EN 228 Super EN 228 Super
EN 228 Super plus EN 228 Super plus
Canadian
standard
CAN/CGSB-3.5 Qualität 1 CAN/CGSB-3.5 Qualität 3
Russian
standard
R 51105-97 R 51866-2002 R 51105-97 R 51866-2002
Regular-91/92 Regular-Euro-92
Premium-95 Premium Euro-95 Premium-95 Premium
Euro-95
Super-98 Super Euro-98 Super-98 Super Euro-98
South African
standard
SANS 1598:2006 SANS 1598:2006
Clean Fuels (CF2) Clean Fuels (CF2)
US standard
ASTM D4814
(min. AKI 87)
ASTM D4814
(min. AKI 91)
Ukrainian
standard
DSTU 4839-2007 DSTU 4839-2007
A-92-Euro
A-95-Euro A-95-Euro
A-98-Euro A-98-Euro
Indian
standard
IS 2796:2008 IS 2796:2008
MG 91
MG 95 MG 95

Rotax 914 series Specifications

General

Bore	79.5 mm
Stroke	61 mm
Compression Ratio	9.0:1
Cooling System	Liquid-cooled cylinder heads, air-cooled cylinders
Redline	5800 rpm
Engine Type	4-cylinder, 4-stroke
Fuel Type	Avgas 100LL
Oil System	Dry sump
Fuel System	fuel injection
TBO (Time Between Overhauls)	2000 hours
Displacement	1.211 liters (1211 cc)
Power Output	84.6 kW (115 hp) at 5, 800 rpm
