Figure 1-2: Controls and Connections
Commandes et branchements
Bedienelemente und Anschlüsse
Controles y Conexiones
De bedieningsorganen en de aansluitingen
Controlli e collegamenti
Kontroller och anslutningar
Органы управления и разъемы
1 2 31 2 3
4
5
6
7 98 0 -
5 7
8
0 =- q w
=
q e re r t y
4
9
6
u
9
: Balanced Output
0
: .Analog Output
-
: Analog Input
=
: Coaxial Input
Connect to coaxial output of the source component.
q
: Bluetooth Antenna
Use for wireless streaming via Bluetooth.
w
: Master Power Switch
e
: Optical Input
Connect to optical PCM outputs of the source component.
r
: PC-USB Input
t
: Service Port
Factory use only service connection.
y
: AC Power Input
u
: Main Fuse
