10
RAS-5000 Amplied Streamer
About Rotel
Our story began over 60 years ago. Over the decades, we have received
of people who take their entertainment seriously – like you.
Rotel was founded by a family whose passionate interest in music led them
Through the years, that passion has remained undiminished and the
family goal of providing exceptional value for audiophiles and music lovers,
regardless of their budget, is shared by all Rotel employees.
new product until it reaches their exacting musical standards. They are
free to choose components from around the world in order to make
the United Kingdom and Germany, semiconductors from Japan or the
United States, while toroidal power transformers are manufactured in
Rotel’s own factory.
We all have concerns about our environment. And, as more and more
electronics are produced it is especially important for a manufacturer
to do all it can to engineer products that have a minimum impact on
the environment.
At Rotel, we are proud to do our part. We have reduced the lead content
in our products by using special lead-free ROHS solder and components.
without compromise to quality. When in standby mode Rotel products use
minimal power to meet global Standby Power Consumption requirements.
The Rotel factory is also doing their part to help the environment through
constant improvements to product assembly methods for a cleaner and
greener manufacturing processes.
All of us at Rotel thank you for buying this product. We are sure it will
bring you many years of enjoyment.
Getting Started
used in a high-quality music audio system, Rotel products will provide
years of musical enjoyment.
This unit is a full featured, high performance component. All aspects of the
design have been optimized to retain the full dynamic range and subtle
nuances of your music. The unit has a highly regulated power supply
incorporating a Rotel custom-designed toroidal power transformer. This
low impedance power supply has ample power reserves, which enables
the unit to easily reproduce the most demanding audio signals. This type
of design is more expensive to manufacture, but it is better for the music.
The printed circuit boards (PCB) are designed with Symmetrical Circuit
Traces. This ensures that the precise timing of the music is maintained
and faithfully recreated. The circuitry uses metal film resistors and
polystyrene or polypropylene capacitors in important signal paths. All
Contents
Important Safety Instructions ...................................2
Figure 1-1: Controls and Connections 3
Figure 1-2: Controls and Connections 4
Figure 2: Remote Control 5
Figure 3: Analog Input and Speaker Output Connections 6
Figure 4: Digital Input Connections 7
Figure 5: Rear HDMI Connection 8
Important Notes 9
About Rotel ...................................................10
Getting Started ................................................10
A Few Precautions 11
Placement 11
Cables 11
The Remote Control ............................................11
Remote Control Batteries 11
AC Power and Control .........................................12
AC Power Input
o
12
Master Power Switch
e
12
Power Switch
1
A
and Power Indicator
2
12
Protection Indicator
2
........................................12
Input Signal Connections ...................................... 12
Aux Input
r
12
Digital Inputs
120
12
Output Connections ..........................................12
PRE Output
t
12
SUB Output
y
13
Headphone Output
3
13
Speaker Outputs
u
...........................................13
Speaker Wire Selection 13
Polarity and Phasing 13
Speaker Connection 13
Display
5
.....................................................13
aptX™ HD Bluetooth Connection
8
............................13
Rear USB port
q
..............................................13
PC-USB Input
-
...............................................13
HDMI eARC Input
p
...........................................14
Network Connection
=w
.....................................14
Streaming ...................................................14
Wi-Fi Stream Connection 14
Audio Streaming 15
Roon Ready ..................................................15
Spotify
®
...................................................... 15
Tidal Connect ................................................15
Overview of Buttons and Controls. . . . . . . . ....... . . . . . . . . . . . . . . . 16
Main Menu ....................................................17
Troubleshooting ............................................... 17
Power Indicator Is Not Illuminated 17
Network Does Not Work 17
Fuse Replacement 17
No Sound 17
Cannot Connect via Bluetooth 17
Playable Audio Formats 18
RAS-5000 APP ................................................19
Specications .................................................19
