17
Dimmer: Sets the brightness of the front display. The Menu Setup will
always activate at the brightest level regardless of the Dimmer setting to
Options include: High (Default), Medium, Low.
LED Dimmer: Sets the brightness of the ON level of the front panel
Power LED.
Options include: High (Default), Medium, Low.
Power On Max Volume: This sets the maximum volume level when the
unit is turned on. “50%” is the factory default.
Options include: 50%-100%.
Auto Power Off: Set the amount of time the units stays powered on when
there is no audio signal. The unit will automatically go to standby mode
Options include: 20 Minutes (Default), Disable, 1 Hour, 2 Hours, 5 Hours,
12 Hours.
Signal Sense: When enabled the unit monitors if an audio signal is
present on the currently selected source. If there is no audio detected
for 10 minutes, the unit will enter Signal Sense Power Mode. When in
Signal Sense Power Mode and the unit detects audio on the Streaming
Input, the unit will automatically power on and begin streaming the
audio. To disable this function, select the “Disabled” option which is the
factory default setting.
NOTE: When the Signal Sense function is activated, the Amplifier
will consume additional power in signal sense standby mode.
Network Info: Shows the network connection status and network settings,
Wi-Fi MAC, Bluetooth MAC and Ethernet MAC.
Software Info: Shows the current software version loaded into the unit.
Wi-Fi Reset: This option erases all current Wi-Fi settings in the unit.
Factory Reset: This option sets the unit back to the original setting as
when it left the factory including resetting the Wi-Fi settings. All user
settings will be erased.
NOTE: Use caution when resetting the unit to factory defaults as all
user configured options will be erased and reset to original factory
settings.
EXIT: Exits this setting menu.
Troubleshooting
or improper control settings. If you encounter problems, isolate the area
fault and make the necessary changes. If you are unable to get sound
from the unit, refer to the suggestions for the following conditions:
Power Indicator Is Not Illuminated
The Power Indicator and the basic items in the Display window should be
illuminated whenever the unit is plugged into the wall power outlet and
the Power button is pushed in. If it does not illuminate, test the power
outlet with another electrical device, such as a lamp. Be sure the power
outlet being used is not controlled by a switch that has been turned off.
Network Does Not Work
If you have trouble connecting to your wired/wireless network, check your
network setting carefully, these steps may help to resolve the problem.
the same network.
section.
4. Do a hard power off (unplug the AC mains) and let the unit restart the
network scanning cycle.
5. If using Wi-Fi connection, make sure the placement of your unit allows
it to receive the Wi-Fi signal.
Fuse Replacement
If another electrical device works when plugged into the power outlet,
but the Power Indicator still will not illuminate when the unit is plugged
into the wall outlet, it indicates that the power fuse may have blown. If you
believe this has happened, unplug the unit removing the AC power and
use the tool to open the fuse holder
i
on the rear panel then replace
the blown fuse with a new one of the exact type and rating, or contact
your authorized Rotel dealer to get the fuse replaced.
No Sound
Check the signal source to see if it is functioning properly. Make sure the
cables from the signal source to the unit inputs are connected properly.
Be sure the Input Source is set to the proper input. Check the wiring
between the unit and the speakers.
Cannot Connect via Bluetooth
If you cannot pair your Bluetooth enabled device to the unit, delete the
memory of the previous connection on your device. On your device this is
often listed as “Forget this Device”. Then try to make the connection again.
