Rotem Platinum Pro - Technical Details and Specifications; Platinum Controller Specifications

Platinum Controllers | 6.0X 6
3 TECHNICAL DETAILS
● Specifications
● Layout
3.1 Specifications
Input Power Voltage
100 – 240 VAC
2.2 Amp, 50-60Hz
Relay Loads
30.0 Amps Active Load; 2 HP Inductive Load, 250 Volts, non-Fused for C-P3-NO-RC-30A relay cards
20.0 Amps Active Load; 1 HP Inductive Load, 250 Volts, non-Fused for C-P3-NC-RC-30A relay cards
20.0 Amps Active Load; 1 HP Inductive Load, 250 Volts, non-Fused for C-P3-WC-RC-30A relay cards
Analog Inputs
0 - 5 Volts, 20 milliamps maximum
Analog Output
0 - 10 Volts
Maximum load: 20 mA
Digital Inputs
5 Volts, 1.5 mA, dry contact
Operating Temperature Range
0° to +50° C (32° to 125° F)
Enclosure
Water and dust tight
Fuses
3 Amps, 250 volts
Certification
