79User manual
Room air conditioner - UKURA X
EN
PART 6. ZATO WIRED CONTROLLER SUPPORT
1. TECHNICAL SPECIFICATIONS
Model ZATO
Power 5V DC
Ambient temperature -5~43°C
Working humidity RH40% ~ RH90%
2. INSTALLATION ACCESSORY
2.1. Select the installation location
Don’t install at the place where contents with heavy oil, vapor or sulfureted gas, otherwise, this product would
be deformed that would lead to system malfunction.
2.2. Preparation before installation
3. Please conrm that all the following parts you have been supply.
No. Name Qty. Remark
1 Wire controller 1 -
2 Cruciform slot screw M4×25 2
This accessory is used when install the wire control
inside the electric cabinet
3 Plastic bolt 2
4 Installation and owner’s manual 1 -
5
The connective wires of display
panel (on some models)
1
For connect between the display panel wire and
shielded 5-core cable
4. Please led install the following accessory.
No. Name Qty. Remark
1 Electric cabinet 1
Universal electric cabinet’s specication. Pre-embed
it into wall.
2 Shielded 5-core cable 1 Pre-embed RVVP-0.5mm2x5 into wall.
3
Wire congured tube (insulated
sheath)
1
Pre-embed into wall, the longest length should not
exceeding than 15m.
4 Phillips screwdriver 1 For install Cruciform slot screw.
5 Slotted head screwdriver 1 For unscrew the bottom cover of wire controller.
Precaution of install the wire control:
1. This manual provides the installation method of wire controller. Please refer to the wiring diagram of this
installation manual to wire the wire controller with indoor unit.
2. The wire controller working in low voltage loop circuit. Forbid to directly contact the cable of
220Vcommercial electricity or of 380V high voltage, and don’t wire this kind of wire in the said loop; wiring
clearance between congured tubes should at the range of 300~500 or above.
3. The Shielded wire of the wire controller must be grounded reliable.
4. Upon nish the wire controller connection, do not employed tramegger to detect the insulation.
