2 x Safety
FA ROTEX HPSU compact (V5) •
7
2.2 Avoid danger
The ROTEX HPSU compact is state-of-the-art
and is built to meet all recognised technical re-
quirements. However, improper use may result
in serious physical injuries or death, as well as
property damage.
To prevent such risks, install and operate
ROTEX HPSU compact only:
– as stipulated and in perfect condition,
– with an awareness of the safety and hazards
involved.
This assumes knowledge and use of the con-
tents of this manual, the relevant accident pre-
vention regulations and the recognised safety-
related and occupational medical rules.
2.3 Proper use
The ROTEX HPSU compact may only be used
for preparation of warm water, as a room heating
system, and depending on its design, as a room
cooling system.
The ROTEX HPSU compact must be installed,
connected and operated only according to the in-
dications in this manual.
Only use of a suitable external unit approved by
ROTEX is permitted. The following combinations
are permissible in this respect:
BIV - Additional heat exxchanger for the bivalent connection
* Not all the equipment mentioned here is offered in some countries because of
the various different country-specific connection conditions.
Tab. 2-1 Permissible combinations of ROTEX HPSU compact internal
units and ROTEX heat pump external units
Any other use outside the intended use is con-
sidered as improper. The operator alone shall
bear responsibility for any resulting damage.
Use as intended also involves compliance with
maintenance and inspection conditions. Spare
parts must at least satisfy the technical require-
ments defined by the manufacturer. This is the
case, for example, with original spare parts.
WARNING!
This equipment must only be used by
children aged 8 and above and by
persons with restricted physical, sensory
or mental capabilities or with a lack of ex-
perience and knowledge, if they are
under supervision or if they have been
instructed in the safe use of the
equipment and understand the dangers
arising therefrom. Children must not
play with the equipment. Cleaning or
user maintenance must not be carried
out by children without supervision.
Internal unit External unit
HPSU compact
304 H/C DB-5 14 15 73
RRLQ004CAV3 14 51 51
HPSU compact
304 H DB-5
14 15 81
HPSU compact
304 H/C Biv-5 14 15 77
HPSU compact
304 H Biv-5
14 15 85
HPSU compact
3
08 H/C DB-5 14 15 74
RRLQ006CAV3
RRLQ008CAV3
14 51 52
14 51 53
HPSU compact
30
8 H DB-5
14 15 82
HPSU compact
308 H/C Biv-5 14 15 78
HPSU compact
308 H Biv-5
14 15 86
HPSU compact
508 H/C DB-5 14 15 75
RRLQ006CAV3
RRLQ008CAV3
14 51 52
14 51 53
HPSU compact
508 H DB-5
14 15 83
HPSU compact
508
H/C Biv-5 14 15 79
HPSU compact
508
H Biv-5
14 15 87
HPSU compact
516 H/C DB-5 14 15 76
RRLQ011CA(V3/W1)*
RRLQ014CA(V3/W1)*
RRLQ016CA(V3/W1)*
14 51 45/48
14 51 46/49
14 51 47/50
HPSU compact
51
6 H DB-5
14 15 84
HPSU compact
516 H/C Biv-5 14 15 80
HPSU compact
516
H Biv-5
14 15 88
