8 x Errors, malfunctions and messages
FA ROTEX HPSU compact (V5) •
61
E9004 7H Fault volume flow Flow sensor FLS
Water flow is too low or there is none at all. Minimum water flow
requ
ired:
– Operating mode "Heating": 600 l/h
– Operating mode "Cooling": 840 l/h
– Automatic defrosting function ( ) active: 1020 l/h
Check the following items:
Ɣ All stop valves of the water circuit must be completely open.
Ɣ Optional water filters must not be contaminated.
Ɣ He
ating system must run within its operating range.
Ɣ Heating system and device-internal circulation pump must be
completely bled.
Ɣ On t
he controller (rotary switch setting "Info" ) check
whether there is adequate water pressure (> 0.5 bar).
Ɣ Check the function of the 3-way switching valve 3UVB1
(compare actual setting of 3UVB1 with BPV position
[Overview] displayed in the parameter).
Ɣ If this fa
ult occurs during defrost operation in the operating
mode room heating or hot water supply? With optional backup
heater: check its power supply and fuses.
Ɣ Ch
eck the fuses in the control housing of the ROTEX HPSU
compact (pump fuse (FU1) on circuit board A1P and printed
circuit board fuse (F1) on the RoCon BM1 circuit board).
Ɣ Ch
eck flow sensor FLS for contamination and function, if
necessary clean, replace.
E9005 8F
Flow temperature
t
V, BH
>75 °C
Flow temperature sensor
t
V, BH
Flow temperature of the backup heater (t
V, BH
) is too high.
– Flow temperature sensor sending incorrect values. Tempera-
ture sensor or connecting cable defective.
Ɣ Check, replace.
– Contact problem A1P-bridge on X3A.
E9006 8H
Flow temperature
t
V, BH
>65 °C
Flow temperature sensor
t
V, BH
E9007 A1 IU main board def Circuit board A1P
Communication between the heat pump exterior equipment and
hea
t pump interior equipment malfunctioning.
– Electromagnetic influences.
Ɣ Perform reset.
– Circuit board A1P defective.
Ɣ Re
place circuit board A1P.
E9008 A5
Coolant tempera-
ture outside of the
val
id range
Temperature sensor (liq-
uid-side coolant) t
L2
No heat absorption at the plate heat exchanger.
Ɣ Check flow.
Ɣ If the flow is OK, then replace the coolant temperature sensor.
E9009 AA
STB fault
Optional: STL Backup
H
eater (BUxx)
Thermal protection switch (STB) on Backup Heater (BUxx) was
tri
ggered.
Ɣ Check and unlock position of STL.
E9010 AC Bridge on board A1P
Bridge of connection socket "X21A" missing on board A1P.
Ɣ Plug in strapping plug.
E9011 C0 Fault flow sensor Flow sensor FLS
Flow sensor FLS defective.
Ɣ Re
place flow sensor FLS.
E9012 C4 Fault feed flow
Flow temperature sensor
t
V2
or t
V, BH
Measurement outside the permitted value range. Sensor or con-
nection cable defective.
Ɣ Check, replace.
E9013 E1 OU main board def
Main board of the heat
pu
mp exterior unit
– Main board in the heat pump exterior unit defective.
– Ventilator motor defective.
Ɣ Check, replace.
Code Malfunction /
Error message
Component/Designation Causes and possible error correction
Display Internal
