66
FA ROTEX HPSU compact (V5) • 
8 x Errors, malfunctions and messages
E198
Flow measure-
ment not plausible
Flow sensor FLS,
3-way diverter valve
3UVB1
Error occurs if the 3-way diverter valve 3
UVB1 is in the Bypass po-
sition, the device-internal circulation pump is running, but the vol-
umetric flow measurement is too low.
Minimum water flow required:
Operating mode "Heating": 600 l/h
Operating mode "Cooling": 840 l/h
Automatic defrosting function ( ) active: 1020 l/h
Air in heating system.
Ɣ Vent.
Device-internal circulation pump not running.
Ɣ Ch
eck electrical connection and control settings. If the
circulation pump is defective, replace it.
Flow sensor FLS contaminated, blocked.
Ɣ Check, clean.
Flow sensor FLS defective.
Valve drive for 3-way diverter valve 3UVB1 defective.
Ɣ Ch
eck, replace.
E200
Communication
fault
Electrical components
Modbus communication between RoCon BM1 and switchboard
A1P i
s disrupted.
Check RTX-AL4 switch board.
Cabling or connections, poor contact.
Ɣ Ch
eck, replace
E8005
Water pressure in
the heatin
g system
too low
Pressure sensor DS
Water pressure has fallen below the minimum permissible value.
Too little water in the heating system.
Ɣ Check heating system for leakage, refill water.
Pressure sensor DS defective.
Ɣ Ch
eck, replace.
E8100 Communication Electrical components
Modbus initialisation also failed after heat pump start-up.
Circuit board A1P defective.
Ɣ Che
ck, replace.
E9000
Temporary internal
message
Not relevant to proper system operation.
W8006
Pressure loss
warn
ing
Pressure sensor DS
Warning message: Maximum permissible pressure drop
exceeded.
Too little water in the heating system.
Ɣ Check
heating system for leakage, refill water.
W8007
Water pressure in
the heatin
g system
too high
Warning message: Water pressure has exceeded the permissible
m
aximum value.
Membrane expansion vessel defective or incorrect pressure
set.
Ɣ Ch
eck, replace.
Setting for the [Max Pressure] parameter too low.
Ɣ If necessary, set
parameter. If setting correct,
Drain water to reduce the system pressure.
Tab. 8-2 Error codes on the main control unit of HPSU compact
Respect the maximum tightening torque of the temper-
ature sensor (see chapter 10.3 "Tightening torque").
Code Malfunction /
Error message
Component/Designation Causes and possible error correction
Display Internal
