FA ROTEX HPSU compact (V5) • 
10 x Technical data
Refrigerant circuit
Number of circuits — 1
Pipe connections
Number — 2
Liquid line
Type — Flanged connection
External Ø inches 1/4" AG
Gas lines
Type — Flanged connection
External Ø inches
5/8" AG
Operating data
Operating range
Flow temperature
for room heat-
ing/cooling function
Heating
(min./m
ax.)
°C
15 to 55
Cooling
(min/max)
°C 5 to 22
Hot water genera-
tion (with BUxx)
Heating
(min./m
ax.)
°C 25 to 80
Noise level
Audibility dBA 42
Noise pressure
2)
dBA 28
Electrical data:
Voltage supply
Phases — 1
Voltage V 230
Voltage range V Voltage ±10%
Frequency Hz 50
Mains connection
3)
Exterior heat pump unit for HPSU
compact
—4G
Exterior heat pump unit — 3G
Option auxiliary
h
eating
Backup Heater
(BUxx)
— 3G (1-phase) / 5G (3-phase)
Order number
Heating/cooling function 14 15 30 14 15 34 14 15 31 14 15 35
Heating function only 14 15 39 14 15 40 14 15 42
14 15 43
Type ROTEX HPSU compact
304 DB 308 DB 304 BIV 308 BIV
