Rotex HPSU compact (V5) Installation And Maintenance Manual

10 x Technical data
FA ROTEX HPSU compact (V5) • 
77
Refrigerant circuit
Number of circuits — 1
Pipe connections
Number — 2
Liquid line
Type — Flanged connection
External Ø inches 1/4" AG 3/8" AG 1/4" AG 3/8" AG
Gas lines
Type — Flanged connection
External Ø inches
5/8" AG
Operating data
Operating range
Flow temperature
for room hea
t-
ing/cooling function
Heating
(min./max.)
°C
15 to 55
Cooling
(min/max)
°C 5 to 22
Hot water genera-
tion (with BUxx)
Heating
(min./max.)
°C 25 to 80
Noise level
Audibility dBA 42 46 42 46
Noise pressure
2)
dBA 28 32 28 32
Electrical data:
Voltage supply
Phases — 1
Voltage V 230
Voltage range V Voltage ±10%
Frequency Hz 50
Mains connection
3)
Exterior heat pump unit for HPSU
compact
—
4G
Exterior heat pump unit — 3G 3G / 5G 3G 3G / 5G
Option auxiliary
h
eating
Backup Heater
(BUxx)
— 3G (1-phase) / 5G (3-phase)
Order number
Heating/cooling function 14 15 32 14 15 33 14 15 36 14 15 37
Heating function only 14 15 41 14 15 38 14 15 44
14 15 45
Performance data
Type exterior heat pump unit
RRLQ006CA
V3/RRLQ008
CAV3
RRLQ011CA
(V3/W1)*/
RRLQ014CA
(V3/W1)*/
RRLQ016CA
(V3/W1)*
RRLQ006CA
V3/RRLQ008
CAV3
RRLQ011CA
(V3/W1)*/
RRLQ014CA
(V3/W1)*/
RRLQ016CA
(V3/W1)*
Nominal heat output A-7/W35 kW 5.29 / 5.53 6 / 8.3 / 8 5.29 / 5.53 6 / 8.3 / 8
Nominal heat output A2/W35 kW 4.6 / 5.51 7.7 / 9.6 / 10.1 4.6 / 5.51 7.7 / 9.6 / 10.1
Nominal heat output A7/W35
kW 6.06 / 7.78 11.8 / 14.8 /
15.3
6.06 / 7.78 11.8 / 14.8 /
15.3
Nominal heat output A10/W35
kW 6.6 / 8.4 11.5 / 14.5 /
16.1
6.6 / 8.4 11.5 / 14.5 /
16.1
Nominal cooling output A35/W18 kW 5.22 / 5.22
15.1 / 16.1 /
16.8
5.22 / 5.22
15.1 / 16.1 /
16.8
Nominal cooling output A35/W7 kW 4.46 / 4.64
11.7 / 12.6 /
13.1
4.46 / 4.64
11.7 / 12.6 /
13.1
Nominal COP A-7/W35
2.73 / 2.78 2.45 / 2.58 /
2.44
2.73 / 2.78 2.45 / 2.58 /
2.44
Nominal COP A2/W35
3.64 / 3.54 3.29 / 3.22 /
3.15
3.64 / 3.54 3.29 / 3.22 /
3.15
Nominal COP A7/W35
4.65 / 4.6 4.47 / 4.27 /
4.
1
4.65 / 4.6 4.47 / 4.27 /
4.1
Nominal COP A10/W35
4.95 / 4.9 4.6 / 4.41 /
4.31
4.95 / 4.9
4.6 / 4.41 /
4.31
Type ROTEX HPSU compact
508 DB 516 DB 508 BIV 516 BIV
