10 x Technical data
FA ROTEX HPSU compact (V5) • 
79
R
S
Sensor resistance (NTC)
tTemperature
t
DHW2
Storage tank temperature sensor
t
R2
Return flow temperature sensor
t
V1
, t
V2
Flow temperature sensor
t
V, BH
Flow temperature sensor Backup Heater
Fig. 10-1 Characteristics of the NTC temperatur
e sensor ROTEX HPSU
compact - part 1
R
S
Sensor resistance (NTC)
tTemperature
t
AU
External temperature sensor RoCon OT1
t
DHW1
Storage tank temperature sensor
Fig. 10-2 Characteristics of the NT
C temperature sensor ROTEX HPSU
compact - Part 2
f Frequency
mFlow
Fig. 10-3 Characteristics of the flow senso
r FLS (V1) ROTEX HPSU
compact
t;
AU
t
DHW1
R
S
Sensor resistance (Pt 1000))
tTemperature
t
R1
Return flow temperature sensor in the flow meter
Fig. 10-4 Characteristics of the return flow temperature sensor in the
flow
sensor FLS (t
R1
) ROTEX HPSU compact
p Water pressure
U Tension
Fig. 10-5 Characteristics of the pr
essure sensor (DS) ROTEX HPSU
compact
