Rotex HPSU compact (V5) Operating Instructions

4 x Parameter settings
BA ROTEX HPSU compact 4 - 03/2013
29
4.9 Rotary switch setting: Info
1. Level 2. Level
Parameter Designation Access Setting range
Min / Max
Factory
setting
Increment
BE HF
T-HS The current (flow) temperature of the heat generator is displayed. S S
T-HS des The current set temperature of the heat generator is displayed in °C with one dec-
imal point.
SS 0.1 °C
T-Outside The current outdoor temperature is displayed in °C with one decimal point. S S 0.1 °C
T-DHW The current temperature of the hot water storage tank is displayed in°C mit with
one decimal point. If no hot water function is activated, "- - -" is displayed.
SS 0.1 °C
T-DHW des We display the current set temperature for the hot water generation in °C with one
decimal point. If no hot water function is activated, "- - -" is displayed. The current
set value is here always the maximum value of all requirements relevant to this hot
water circuit.
SS 0.1 °C
T-Return The current return temperature of the heat generator in °C with one decimal point
is displayed. If there is no corresponding sensor connected to the heat generator,
"- - -" is displayed.
SS 0.1 °C
Flow Rate The filtered value of the current volume flow is displayed. S S l/h
T-HC The temperature of the direct heating circuit is displayed in °C with one decimal
point.
SS 0.1 °C
T-HC Setpoint The set (flow) temperature of the direct heating circuit is displayed in °C with one
decimal point.
SS 0.1 °C
Water Pressure The current water pressure is displayed in bar. S S 0.1 bar
Runtime Compres-
sor
The running time of the compressor is displayed in h. S S h
Runtime Pump The running time of the pump is displayed in h. S S h
Qboh The quantity of heat in the reserve heating for hot water generation is displayed in
kWh.
SS 0.1 kW
Qchhp The quantity of heat in the reserve heating for heating is displayed in kWh. S S 0.1 kW
Qsc The quantity of heat in the heat pump for cooling is displayed in kWh. S S 0.1 kW
Qch The quantity of heat in the heat pump for heating is displayed in kWh. S S 0.1 kW
QWP The total amount of heat in the heat pump is displayed in kWh. S S 0.1 kW
Qdhw The quantity of heat for hot water generation is displayed in kWh. S S 0.1 kW
SW Nr CUI The software and version of the operating unit is displayed. S S -
SW Nr Controller The software number and the version of the regulating board are displayed. S S -
SW Nr. RTX RT The software number and the version of the modbus board are displayed. S S -
Mixer Position The current position of the 3UV1 mixer is displayed in %. S S -%
Tab. 4 -8 Parameter in rotary switch setting "Info"
