12
8 - Approvals
Maximum Constructional Flamepath Gaps
Flamepath
Max. Gap
(mm)
Min. Length
(mm)
Equipment Type
Electrical Cover / Back Housing
0.15 26.00 All Types and Sizes
Terminal Cover / Back Housing
ATEX / IECEx
0.15 12.50 RHS
Terminal Cover / Back Housing for FM & CSA
0.115 12.50 RHS
Transfer Loom Bush for FM & CSA
0.115 25.00 RHS
Transfer Loom Bush Flamepath
0.15 25.00 RHS
Vibration, Shock and Noise
Standard IQ remote hand stations are suitable for applications
where vibration and shock severity does not exceed the
following:
Type Level
Plant induced
vibration
1g rms total for all vibration within the frequency
range of 10 to 1000 Hz
Shock
5g peak acceleration
Seismic
2g acceleration over a frequency range of 1 to
50 Hz
if it is to operate during and after the event
Emitted noise
Independent tests have shown that at 1m
generated noise does not exceed 65 db(A)
ATEX / IEC / CSA / Certified RHS
SPECIAL CONDITIONS
This Remote Hand Station must only be located in areas
where the risk of impact to the viewing window is low.
This equipment includes some exterior non-metallic paints
including the protective coating. To avoid the possibility of
static build up, cleaning must only be carried out with a water
dampened cloth.
For CAN / CSA C22.2 No. 61010-1-12 compliance the RHS
must be connected to an IQ3 or IQT3 actuator.
THREAD DETAILS FOR ATEX AND IECEx APPROVAL
Threaded
Flamepath
Thread
Size
Thread
Length
Equipment Type
Cable Entry
M25x1.5 20.00 All Types and Sizes
EXTERNAL ENCLOSURE FASTENERS
Enclosure fasteners are stainless steel grade A4-80 M8 for the
main display cover and 12.9 M5 for the terminal cover.
