Royal Enfield Bullet 500 User Manual

47
FRONT WHEEL REMOVAL
Us e onl y s tanda rd tyres & tub es inf l at ed to
correct pressure.
Frontt
Re ar
WARNING
Tyres, rims and air valves must be correctly
matched to wheel rims. See your Royal Enfield Dealer.
Mismatching tyre, tubes, rims and air valves may
result in damage to the tyre bead during mounting,
allow tyre slippage on the rim and cause tyre failure.
Place the vehicle on center stand
Place a wooden block
th e fr ont en d of
engine to support the
vehicle.
Di s conn ec t s pee do
cable.
Loosen the pinch bolt
on the RH fork guide.
Ho l d fr o nt axle b y
spanner an d loosen
axle nut then remove
nut along with washer.
MINOR MAINTENANCE TIPS
Solo 1.41 kg/cm2 2.11 kg/cm2
(20 PSI) (30 PSI)
With Pillion 1.55 kg/cm2 2.25 kg/cm2
(22 PSI) (32 PSI)
TYRE PRESSURE

Royal Enfield Bullet 500 Specifications

General

Engine Type	Single Cylinder, 4 stroke, Air cooled
Displacement	499 cc
Bore x Stroke	84 mm x 90 mm
Compression Ratio	8.5:1
Maximum Power	27.2 bhp @ 5250 rpm
Maximum Torque	41.3 Nm @ 4000 rpm
Fuel System	Electronic Fuel Injection
Clutch	Wet, multi-plate
Transmission	5 Speed Constant Mesh
Frame Type	Single downtube, using engine as stressed member
Front Suspension	Telescopic, 35 mm forks, 130 mm travel
Front Brake	280 mm Disc, 2-Piston caliper
Rear Brake	153 mm Drum, Single Lead Internal Expanding
Front Tyre	90/90 - 19
Rear Tyre	120/80 - 18
Kerb Weight	194 kg
Seat Height	800 mm
Ground Clearance	135 mm
Wheelbase	1370 mm
Ignition System	Transistorised Coil Ignition (TCI)
Rear Suspension	Twin shock absorbers with 5-step adjustable preload
Fuel Tank Capacity	13.5 L
