"CRUSADER
250," "250
CLIPPER"
AND
"CRUSADER
SPORTS"
the rear light cable, the complete assembly can be
removed.
See
Fig. 11.
When replacing, engage the front clip first and drop
the assembly into position. When tightening the nuts
make sure that the shoulders of the nuts are right home
in the recesses on the inside of the carrier attachment
brackets.
49
Fitting a
New
Rear Chain.
Place
the machine on
the centre stand and remove the rear section of the rear
chain case after unscrewing the three screws holding it
to the rear brake cover plate. Disconnect the chain
at
the connecting link, join up the new chain to the old
one and pull it into the chain case by pulling out the old
one. Disconnect the old chain and join up the new one,
making sure that the closed end of the spring clip points
in the direction of travel of the chain. Check for correct
chain tension and, if necessary, adjust as described in
Section
42.
50 Removal of Tyres. The wired-on tyres fitted are
easily removed if the correct procedure is adopted.
Deflate the tyre by unscrewing the inside of the valve
with the key formed on the dust cap. Remove the
milled locknut securing the valve to the rim.
At
a point
opposite the tyre valve, press the walls of the tyre down
into the well in the centre of the rim, and work the walls
down into the
well
as far as possible in either direction.
It
will then be found possible to lever
off,
starting
at
a
point near the valve and working in either direction.
When replacing the cover reverse this procedure, starting
opposite the valve and finishing close to it with the
tyr6
at the opposite side of the wheel pressed down into the
rim. When only slightly inflated, see that the wired edges
are in their proper places, not down in the well. As a
check on
this,
examine the fine line moulded on the wall
40
