ROYAL ENFIELD 350cc and 500cc O.H.V. WORKSHOP MANUAL
Page 6
DATA-continued
CARBURETTER.
Carburetter Type ............. .......... ... ....... .......... Amal. 276
Main Jet Size .................. ... ....... ... ....... ... ....... ... ....... ... ........ 130
Throttle Valve ................ ... ....... ... ....... ... ....... ... ....... ... ........ 6/4
IGNITION.
Contact Breaker Maximum opening ... ... ... .012 in.
Ignition Setting ... ... ... ...
3
/
8
in. before t.d.c.
= 34° advance.
Sparking Plug-Size ................... ... ....... ... ... 14 m.m.
1
/
2
in. reach.
Type .......................................... ... ....... ... ..... Lodge C.14 Sintox.
................................................... .......... ....... or Champion L.10S.
Gap Setting ............................... .......... ... .018 in. to .020 in.
GENERAL.
Petrol Tank Capacity 2
3
/
4
gallons (including
1
/
4
gallon reserve).
Oil Tank Capacity ... ... ... ... ... 4 pints.
Gear Box Capacity ... ........ .. ....... ... ....... ... ....... ... ...
3
/
4
pint.
TOOLS SUPPLIED WITH MACHINE
TOOL ROLL AND CONTENTS
No. per Part Description.
Set No.
1 28996 Swivel Pin and Chain Adjuster Spanner
(to fit 5/16" square).
1 16008 Magneto Spanner (.255" x .283" hex.
with .012" feeler).
1 29101 Pump Cover Pin Spanner (.255" hex.
with .018" feeler).
1 4272 Tyre Lever (cranked type).
2 4272A Tyre Levers (spoon type).
1 3482 Screwdriver, 6", wire.
1 14835 Extractor Nut (Dynamo Pinion).
1 16014 Grease Gun.
1 16007 Tool Roll (with strap-less tools).
4 25861 Hallite Washers for Push Rod Tubes.
No. per Part Description.
Set No.
1 29044 Double-ended Spanner-Engineers' Patt.
(1/4" x 5/16" Whit.)
1 2976 (3/8" x 7/16" Whit.)
1 24092 .380" x .343" hex.
-also .380" sq.)
2 24096 (3/16" x 1/4" Whit.)
1 28976 Tubular Spanner (1/4" Whit.)
(For Cylinder base nuts)
1 16594 (9/16" Whit.)
1 21166 (7/16" Whit.)
1 24094 (11/16" Whit.)
1 29043 (3/16" Whit.)
1 24097 (5/16" x 3/8" Whit.)
1 29042 Tommy Bar (Bent)
SUPPLEMENTARY KIT
1 27388 Chain Rivet Extractor.
1 27387 Tyre Repair Outfit.
1 29382 Box of Spare Links (5/8" pitch chain).
1 27383 Packet of insulating Tape.
2 27386 Leather Straps.
1 27528 Oil Can.
1 27389 Oil Funnel.
1 27575 Pliers, 7".
1 27574 Adjustable Spanner, 7".
1 27576 Screwdriver, 6".
