E25 Filling motor could not go
to home position. Gripper
is closed.
• Gripper must be open.
• ! malfunction.
E26 Not allowed to start Filling
motor. Carousel is not at a
defined position.
•
! malfunction.
E27 Filling motor could not go
down all the way. Gripper
is closed.
• Gripper must be open.
• | malfunction.
E28 Filling motor pulse disk
error.
No pulses were detected. Position of
filling motor unknown.
• Pulse disk malfunction.
• | jammed or malfunction.
E29 (Number not assigned)
E30 (Number not assigned)
E31 Carousel could not turn.
Gripper is closed.
• Gripper must be open.
• Gripper sensors malfunction.
E32 Carousel could not turn.
Measure head not at home
position.
• | malfunction.
E33 Carousel could not turn.
Nozzle not at home
position.
•
! malfunction.
•
