Installation
Page 32 Starrsed ST Service manual
Version <Book_version> MRN-<MRN_number>-<language_code>
5. INSTALLATION
Before unpacking the <Instrument>, we recommend that the packaging should be checked for
damage. Any damage must be reported to the distributor.
Follow the next installation instruction steps.
5.1. Unpacking <Instrument> system
1. Cut the binding of box and take out
the top protection cover.
2. Remove the out box.
3. Remove the accessories box.
4. Remove the plastic bag from the
<Instrument>.
5. Lift the <Instrument> from the bottom
protection cover onto a table.
5.2. Install at chosen location
Install the <Instrument> in a location with the following specifications,
1. Avoid direct sunlight shining on the <Instrument>.
2. Avoid droughts which may cause temperature changes.
3. Place the <Instrument> on a stable table, with no nearby vibration.
4. Do not place in direct airflow of an air conditioning unit.
5. Leave a space of approximately 15 centimeters between the back side of the instrument and
the wall to allow warm air to escape and to connect or run interface cables.
6. Use a power connection with a proper earth connection.
7. Level the instrument by using the three adjustable feet and the leveling-gauge, which is
situated at the carousel.
