RR Mechatronics Starrsed ST - Explanation of symbols

General introduction
Starrsed ST Service manual Page 29
Version <Book_version> MRN-<MRN_number>-<language_code>
Label Number
Function
Part number
Replacement of
S3 Carousel position sensor BANG029003
S4 Measure head BANG089004
S5 Waste sensor BANG019017
BANG019005/BANG0
19015
S6 Blood sensor BANG080013
S7 Nozzle top sensor QEOP100005
S8 Nozzle bottom sensor QEOP100005
S9 Filling home sensor QEOP100005
S10 Piston detection sensor QEOP100005
S11 Carrousel motor home sensor QEOP100005
S13 Measuring home sensor QEOP100005
S14 Diluent level sensor BANG019006
S15 X-Clean level sensor BANG019006
S16 Gripper home sensor QEOP100005
S17 Gripper close sensor QEOP100005
S18 Needle home sensor QEOP100005
S19 Needle bottom sensor QEOP100005
S21 Temperature sensor on BANG080004
