27
4
OT
Over temperature alarm sign
0: The driver temperature is normal
1: The internal components temperature of the driver is too high
3
UV
Under-voltage alarm sign
0: No under-voltage alarm
1: The driver is under-voltage
2
OV
Over-voltage alarm sign
0: No over-voltage alarm
1: Over-voltage occurs in the drive, and the following check are
required:
 Check the input power
 Check the pumping voltage when the motor is decelerating
1
OC
Over-current alarm sign
0: No over-current alarm
1: The drive has an over-current alarm, the possible reasons are as
follows:
 The motor winding is short-circuited
 The current set by the driver is too large, causing the motor to burn
out
 Internal components of the driver are damaged
0
IVE
Internal voltage error alarm flag
0: No internal voltage error
1: Internal voltage error, usually caused by damage to the internal
components of the driver
2．Driver status flag register [1]
Some status flags inside the driver are defined. MODBUS address: 1
15
11
10
9
8
Reserve
POW
NL
PL
R-0
7
6
5
4
3
2
1
0
CLAMP
ARRSPD
RDY
HOME
MOV
INPOS
ALM
ENA
R-0
R-0
R-0
R-1
R-0
R-0
R-0
R-1
