EP Series User Manual
34
6．Input port shutdown edge clear register [7]
Used to clear the latched shutdown edge flag. MODBUS address: 7
15
8
Reserve
R-0
7
6
5
4
3
2
1
0
Reserve
IN6
IN5
IN4
IN3
IN2
IN1
R-0
R/W-0
R/W-0
R/W-0
R/W-0
R/W-0
R/W-0
Table 3-9 Register details [7]
BIT
Name
Description
6～15
Reserve
Read always returns 0.
5
IN6
Clear the shutdown edge latch state flag of IN6
0: No effect
1: Clear the shutdown edge latch flag of the IN6 port
4
IN5
Clear the shutdown edge latch state flag of IN5
0: No effect
1: Clear the shutdown edge latch flag of the IN5 port
3
IN4
Clear the shutdown edge latch state flag of IN4
0: No effect
1: Clear the shutdown edge latch flag of the IN4 port
2
IN3
Clear the shutdown edge latch state flag of IN3
0: No effect
1: Clear the shutdown edge latch flag of the IN3 port
1
IN2
Clear the shutdown edge latch state flag of IN2
0: No effect
1: Clear the shutdown edge latch flag of the IN2 port
0
IN1
Clear the shutdown edge latch state flag of IN1
0: No effect
1: Clear the shutdown edge latch flag of the IN1 port
