ES-2310C User Manual
Publication date: Aug., 2010
Revision A5
121
Function name:
Restricted Group
Function description:
The function of the Restricted Group can decide the direction of transmitting
packets for the specific port. The packets received by the port with the
“Ingress” mode of Restricted Group will be sent to the ports with the “Egress”
mode of Restricted Group.
Parameter description:
Mode:
Used for the activation or de-activation of Restricted Group function.
Default is disable.
Ingress:
Select the ports that you would like their Restricted Group to set into
“Ingress” mode. Just tick the check box beside the port x and valid port is
Port 1~10.
Egress:
Select the ports that you would like their Restricted Group to set into
“Egress” mode. Just tick the check box beside the port x and valid port is
Port 1~10.
Fig. 3-59
