ES-2310C User Manual
Publication date: Aug., 2010
Revision A5
7
• LED Indicators
LED Color Function
System LED
CPURUN Green Lit when CPU is on and good
POWER Green Lit when AC power is on and good
10/100Mbps Ethernet TP Port 1 to 8 LED
LNK/ACT/SPD
Green/
Amber
Green Lit when 100Mbps connection with
remote device is good
Amber Lit when 10Mbps connection with remote
device is good
Blinks when any traffic is present
Off when cable connection is not good
FDX/COL
Amber
(TP Port 1
to 8 LED)
Lit when full-duplex mode is active
Blinks when any collision is present
10/100/1000Mbps Gigabit TP/Fiber Port 9, 10 LED
LNK/ACT/SPD
Green/
Amber
Green Lit when 1000Mbps connection with
remote device is good
Amber Lit when 100/10Mbps connection with
remote device is good
Blinks when any traffic is present
Off when cable connection is not good
SFP LNK Green
Lit when Fiber port is active
Off when TP port is active
Table1-1
