ES-2310C User Manual
Publication date: Aug., 2010
Revision A5
240
Hardware Specifications
Standard Compliance: IEEE802.3ab / 802.3z / 802.3u / 802.3x
802.3z and 802.3ab compliant Gigabit Ethernet ports
Network Interface of Option transceiver:
Configuration Mode Connector Port
SFP.LC
1000FDX *LC M-M
2(Option)
SFP.LC.SXX
1000FDX *LC S-M
2(Option)
SFP.BL3(5).SXX
1000FDX
*BiDi-LC S-M
2(Option)
* : Default module
Transmission Mode: 10/100Mbps support full or half duplex
1000Mbps support full duplex only
Transmission Speed: 10/100/1000Mbps for TP
1000Mbps for Fiber
Full Forwarding/Filtering Packet Rate: PPS (packets per second)
Forwarding Rate Speed
1,488,000PPS 1000Mbps
148,800PPS 100Mbps
14,880PPS 10Mbps
MAC Address and Self-learning: 8K address table entries,
256 VLAN table entries,
256 IP multicast table entries,
Buffer Memory: Embedded 256KB packet buffers and 128KB control memory.
Flow Control: IEEE802.3x compliant for full duplex
Backpressure flow control for half duplex
Cable and Maximum Length:
TP
Cat. 5 UTP cable, up to 100m
1000Base-SX SC M-M
Up to 220/275/500/550m,
which depends on Multi-Mode Fiber type
1000Base-LX SC S-M
Single-Mode Fiber, up to10/30/50Km
1000Base-FX WDM SC S-M
Single Fiber, BiDi 20Km
