ES-2310C User Manual
Publication date: Aug., 2010
Revision A5
73
Add Group:
Create a new Port-based VLAN. Input the VLAN name and choose the
member by ticking the check box beside the port No., then, press the
<Apply> button to have the setting taken effect.
Fig. 3-25
Delete Group:
Just press the <Delete> button to remove the selected group entry from
the Port-based group table.
Fig. 3-26
Edit a group:
Just select a group entry and press the <Edit> button, then you can
modify a group‘s description and member set.
