Ruffneck AH-12A - F.2 Ah-24 B

13
Parts List
F.2 AH-24B
Item Description AH-24B
1 Panel, AH Top/Bottom 5394
2 Panel, AH Right Side 5392
3 Panel, AH Shroud 5391
4 Fan 5451
5 Fan Guard (half) 5396
6 Motor ***
7 Bracket, Motor Mount Right 3789
8 Channel, Motor Mount 5433
9 Bracket, Motor Mount Left 3788
10 Panel, AH Left Side 5393
11 Heat Exchanger
**
12 Kit, Louver (c/w screws) 5742
For disconnect parts list, see F.3, page14
